Multifunctional Microwave Chemistry Reaction Workstation

Microwave source

2450MHz,   0-1000W, continuous, non-pulse and automatically adjustable along with the   temperature program, PID technology

Microwave oven chamber

Large   volume, 316L stainless steel chamber, applied with multi-layer anticorrosive   PFA Teflon spray inside and outside

Temperature measuring and   control system

Dual-channel   temperature detection DTD technology, switchable control. Infrared   temperature sensor range 0~900℃, precision ±1℃,   PT-100 resistor temperature sensor range 0~250℃, precision ±1℃

Pressure measuring and   control system

Piezoelectric   crystal pressure sensor, pressure control range: 0~5MPa (750psl), precision   of ±0.01   MPa

Working temperature

standard   configuration instrument’s   maximum operating temperature is 300℃ and the maximum theoretical   operating temperature is 900℃(peculiar   configuration). The standard maximum working temperature of high-pressure   reaction is 230℃.

Working pressure

The   standard maximum working pressure of high-pressure reaction is 2 MPa, with   constant pressure control valve, and constant pressure value of 2 MPa.

UV light source system

It   can be equipped with two sets of ultraviolet light, with UV power of 300W and   the dominant wavelength of 365nm (standard); UV power of 100W and the   dominant wavelength of 254nm (optional)

Ultrasonic system

Immersion   ultrasonic launcher, with adjustable scope of ultrasound power: 0 - 800W,   frequency of 28KHZ, and automatic frequency sweeping and frequency locking

Stirring system

Digital   constant speed mechanical stirring, with rotation speed of 30 - 1600r/min. It   can realize real-time speed regulation and displays ±10r/grade,   with torque of 300 N.m. It can stir clockwise or anticlockwise; Built-in   magnetic stirring rotation speed of 0~800r/min, speed program is adjustable   and of real-time display.

Software system

With   Windows software and 7-inch color LCD touch screen, it can make accurate   setting and real-time display of various parameters and curves, and can   transmit the reaction parameters and curves by connecting with the computer,   and record and realize the control or change of each reaction process   unlimitedly;

Video system

Color   image recording system is equipped, which can realize real-time display of   reaction process through 7-inch color LCD screen. And it can realize the   transmission and recording by connecting the computer.

Interface

USB2.0   Serial port

Exhaust system

Oven   chamber is equipped with high-speed hot blast fan, with blast capacity of   3m3/min. 3-gear speed change will be made automatically according to the   reaction situation

Atmospheric pressure reaction   vessel

Standard   50~1000ml high borosilicate glass reaction vessel and condensation, reflux,   charging accessories, optional 2000ml high borosilicate glass vessel,   optional 50~1000ml quartz reaction vessel

High pressure reaction vessel

100ml,   200ml and 500ml TFM high pressure digestion inner vessel, aerospace   composite fiber explosion-proof outer vessel, high-strength alloy frame

Working environment   temperature/humidity

0~40℃/15~80%   RH

Physical size of whole   machine

500*625*580   (Width×depth×height),   48kg
