-25℃ Biomedical Freezer

Product ID: MDF-25V936

The -25 deep freezer offers a large capacity storage space.

Integrated design of cold shelf and evaporator provides additional refrigeration efficiency.



This products designed to store vaccines blood plasma, and many other biological materials, Installations can be found in researching institution and clinical sites in life science, electronic testing and medical markets.



Features

l  Chemically stable, CFC-free, commercially available and environmentally, safe refrigerant.

l  High density foam insulation for rigidity and stable storage temperature. Microprocessor control, digital display adjustable temperature rage: -10--25.

l  LED digital display for clear observation.

l  Wide voltage tolerance design with applicable voltage range of187~242 V/AC.



Safety

l  Multiple malfunction alarms including high and low temperature , sensor error

l  Two types of alarm indications: audible buzzing and visible flashing light.

l  Door lock for storage safety



Humanized design

l  Upright side door with build-in handle for easy-opening; limit door hinge to prevent collision when door open .

l  Lockable caster design for customer to move as needed .

l  Controller password protect function to avoid change running parameter randomly.



Certificate:

l  ISO14001.ISO9001.ISO13485.ISO45001.



Warranty

l  1 year free spare parts and remote technical support.



Special

       Environmentally friendly refrigerant

       Easy-to-clean sprayed steel plate material;Not easy to adhere to dust





Performance


Refrigeration System

Temperature Range

-10~-25°C

Compressor/Brand

SECOP/2

Ambient Temperature

+10~+32°C

Refrigerant

R404A

Controller

Microprocessor

Cooling Type

 Direct cooling

Display

Digital Display

Defrost Type

Manual




Electrical Data


Dimensions

Power Supply(V/Hz)

220~240V/50~60;115/60

Capacity

936L

Rated Power(W)

1000W

Interior Size(W*D*H)

1000*700*1335mm

Electrical Current(A)

5.8

Exterior Size(W*D*H)

1320*980*2100mm

Power Consumption

10 kWh/24h

Package Size(W*D*H)

1360*1135*2170mm

Power failure alarm

72 H


N.t./G.t.(approx)

377/421 kg




Loading Qty(20'/40'/40'H)

8/16/16









Alarm


Accessories

High/Low Temperature

Y


Caster

4

Sensor Error

Y


Remote alarm port

Y

Power Failure

Y


Inner Door

4

Door ajar

Y


Shelf

3

Thermostat failure

Y


Test hole

1/25MM

Condenser clean

Y


Data logger

Optional
