Fluorescence Spectrophotometer

Fluorescence Spectrophotometer
Model ID: FS-F98

F98 fluorescence spectrophotometer is a new generation of high-performance molecular luminescence analysis equipment. This product is designed for high performance, with high signal to noise ratio, ultra-high scanning speed, ultra-high resolution, ultra-high wavelength accuracy and a variety of accessories. This instrument easily meets the requirements in material research, drug analysis, biochemical and clinical testing, water quality control, food safety testing and other areas of qualitative and quantitative analysis and scientific research. Quantum yield accessory is available for F98 fluorescence spectrophotometer.

Main Features:

l Horizontal slit optical design, with excellent luminous detection efficiency and high signal to noise ratio. Water Raman peak SNR better than 350: 1 (P-P) or 18000: 1 (RMS BG). The minimum sample volume is 0.5mL when using a standard 10mm square sample cell.

l Wavelength scanning speed up to 60000 nm / min.

l Bandwidth 1/2/5/10/20nm adjustable.

l Fluorescence Quantum Yield accessory available.

l The software offers fluorescence 3D scanning, equal-wavelength difference synchronous scanning, equal wave number difference (constant energy difference) synchronous scanning functions. (synchronous scanning function require pro version software)

l Multi accessories available.

l Using Hamamatsu’s high quality Xenon light source and photoelectric multiplier tube detectors and instruments to provide sufficient light intensity signal and the detection sensitivity.

l Built-in frequency filters at 270/420/510/580nm in both excitation and emission monochromator. Built-in optical gate, designed for unstable sample.

Specification of F98 Fluorescence Spectrophotometer
Excitation Source	150W xenon lamp (Hamamatsu)
Excitation Wavelength	200nm~900nm
Emission Wavelength	200nm~900nm
Excitation Slit	1nm/2nm/5nm/10nm/20nm
Emission Slit	1nm/2nm/5nm/10nm/20nm
Wavelength Accuracy	±0.4nm
Wavelength Repeatability	≤0.2nm
Signal-to-Noise Ratio	S/N≥350(P-P); S/N≥1500(RMS); S/N≥18000(RMS BG)
Limit	≤5×10^-11 g/ml (Quinine Sulfate Solution)
Linearity	γ≥0.995
Peak Repeatability	≤1.5%
Wavelength Scan Speed	Multi-speed Level, Maximum at 60000nm/min
Minimum sample size	0.5mL (Using a standard 10mm square sample cell)
Filters	Build in filters Ex/Em 270/420/510/580nm
Photometric Quantity Range	-9999.99 ~ 9999.99
Response Time	0.02/0.1/0.5/1/2/4/8 s，Auto adjust
Data Transportation	USB2.0
Power	200W
Power Source	AC 100-240V, 50/60Hz
Instrument Dimension	610×460×365 (mm)
Weight	Net Weight: 21kg Gross Weight: 47kg
